Buy 20/40’ Slider 12 Pins Tandem Chassis online

The 20/40’ Slider 12 Pins Tandem Chassis is engineered for optimal performance and versatility, specifically designed to transport a wide range of ISO containers, including one 20-foot ISO container, two 20-foot empty containers, or one 40-foot ISO container. This chassis is built to meet the demanding needs of the shipping, logistics, and transport industries, offering unmatched durability and compliance with all major safety and industry standards, including DOT, AAR, ANSI, TOFC, FMVSS, SAE, and TTMA specifications.

Versatile and Efficient Container Transport

This 20/40’ Slider 12 Pins Tandem Chassis is a highly adaptable solution designed to accommodate various container configurations. Whether you are transporting a single 20-foot container, two empty 20-foot containers, or a full 40-foot container, this chassis is designed to handle the load with ease. The slider mechanism allows the chassis to extend from 36’ 10 15/16” when retracted to 45’ 6 3/16” when fully extended, providing the flexibility needed to manage different cargo sizes and optimize your transport operations.

The tandem axle configuration enhances the chassis’s stability and load distribution, ensuring smooth and safe transport, even under heavy loads. With a maximum payload capacity of 49,400 lbs in the 20-foot position and 67,200 lbs in the 40-foot or 45-foot position, this chassis is built to handle the most demanding transport tasks. Whether you are moving industrial equipment, heavy machinery, or large shipments of goods, the 20/40’ Slider 12 Pins Tandem Chassis offers the durability and reliability required for efficient transport.

Built to Meet the Highest Safety Standards

Safety and compliance are at the forefront of the design of the 20/40’ Slider 12 Pins Tandem Chassis. This chassis meets all critical industry standards, ensuring that it is safe and compliant for use in various transportation scenarios. The chassis is built to DOT (Department of Transportation) and AAR (Association of American Railroads) standards, making it suitable for both road and rail transport. Additionally, it meets ANSI (American National Standards Institute), TOFC (Trailer on Flatcar), FMVSS (Federal Motor Vehicle Safety Standards), SAE (Society of Automotive Engineers), and TTMA (Truck Trailer Manufacturers Association) specifications, providing a comprehensive solution that meets all industry requirements.

The kingpin location is precisely positioned at 24 inches from the rear face of the front bolster, ensuring optimal weight distribution and stability during transit. The landing gear is located 94.5 inches from the centerline of the kingpin, providing robust support during loading and unloading operations. The tridem location is positioned 25 7/8 inches from the rear face of the rear bolster, further enhancing the chassis’s balance and control, even under heavy loads. The axle spread of 61” + 61” ensures that the load is evenly distributed across the chassis, reducing stress on the axles and improving the overall lifespan of the chassis.

Technical Specifications

• Overall Length: 36’ 10 15/16” retracted or 45’ 6 3/16” extended
• Overall Width: 96” (over tire 102”)
• Fifth Wheel Height: 47 ± 1 inch
• Max Rear Height: 48 ± 1 inch
• Kingpin Location: 24 inches from the rear face of the front bolster
• Landing Gear Location: 94.5 inches from the centerline of the kingpin
• Tridem Location: 25 7/8 inches from the rear face of the rear bolster
• Axle Spread: 61” + 61”
• Tare Weight: 10,210 lbs ± 2%
• Payload Capacity: 49,400 lbs in the 20-foot position; 67,200 lbs in the 40-foot or 45-foot position

Benefits of the 20/40’ Slider 12 Pins Tandem Chassis

Versatility in Transport: The adjustable length and tandem axle configuration make this chassis suitable for various container configurations, including one 20-foot container, two empty 20-foot containers, or one 40-foot container. This versatility makes it an essential asset for any transport fleet.

High Payload Capacity: With a maximum payload of up to 67,200 lbs in the 40-foot or 45-foot position, this chassis is built to handle heavy and demanding loads, ensuring efficiency in your transport operations.

Safety and Compliance: Meeting all major safety and industry standards, including DOT, AAR, ANSI, TOFC, FMVSS, SAE, and TTMA, this chassis ensures that your transport operations are both safe and compliant with regulations.

Durability and Reliability: Constructed with high-quality materials and designed for heavy-duty use, the 20/40’ Slider 12 Pins Tandem Chassis offers long-term reliability and reduced maintenance costs, ensuring that your investment is protected over time.
