Buy 40ft-45ft-48ft-53 Extendable Chassis online

The 40ft-45ft-48ft-53ft Extendable 60″ Spread 3-Axle Chassis is a versatile and high-capacity transport solution designed to accommodate multiple container sizes on a single trailer. Whether you need to haul a 40-foot, 45-foot ISO container, or a 48-foot to 53-foot domestic container, this chassis is built to deliver exceptional performance and adaptability. Engineered with a telescoping beam system, the chassis can extend thirteen feet from its closed position, allowing it to fit different container sizes securely on the same four pins.

This extendable container chassis is proudly assembled in the USA, utilizing state-of-the-art fabrication, welding, and paint systems to ensure durability and longevity. Designed for heavy-duty use, it is an essential tool for logistics companies, shipping operators, and anyone needing a reliable and flexible container transport solution.

Versatile and Adaptive Container Transport

The 40ft-45ft-48ft-53 Extendable Chassis offers unmatched versatility, allowing you to transport four different container sizes with ease. The telescoping beam system is the key feature, providing the ability to extend the chassis from 40.6 feet when closed to 53.6 feet when fully extended. This adjustability is crucial for optimizing load distribution and ensuring safe and secure handling of various container sizes.

The overall length can be adjusted to fit containers ranging from 40-foot ISO containers to 53-foot domestic containers, making it a versatile addition to any fleet. This flexibility reduces the need for multiple chassis types, streamlining operations and reducing costs for transport companies.

Built for Strength and Durability ( 40ft-45ft-48ft-53 Extendable Chassis)

Constructed with ASTM-A572 Grade 50 or ASTM-A607 Grade 50 structural steel, the 40ft-45ft-48ft-53ft Extendable Chassis is designed to withstand the rigors of heavy-duty transport. The steel components are fabricated for maximum strength, ensuring that the chassis can handle the toughest conditions. All structural fasteners are Grade 5 or better, zinc-coated to prevent corrosion and extend the lifespan of the chassis.

The upper coupler assembly features a 5/16″ thick pick-up plate, providing a robust connection between the chassis and the container. The front bolster is fabricated with a channel design and steel casting end plates, made to accept genset plugs and wiring, enhancing the functionality of the chassis for different transport scenarios. The rear bolster is a channel type, adding to the structural integrity and load-bearing capacity of the chassis.

High Payload Capacity and Compliance of 40ft-45ft-48ft-53 Extendable Chassis

With a Gross Vehicle Weight Rating (GVWR) of 90,000 lbs, the 40ft-45ft-48ft-53ft Extendable Chassis is built to handle heavy loads with ease. The tare weight of approximately 10,800 lbs ensures that the chassis remains lightweight yet strong, maximizing the payload capacity and operational efficiency. This chassis is compliant with all DOT, AAR, ANSI, TOFC, FMVSS, SAE, and TTMA specifications, making it suitable for various transport environments and ensuring it meets industry standards for safety and performance.

The suspension system features a sliding one-leaf spring ride, providing a smooth and stable ride even under heavy loads. The axle system includes three 5-inch round, tapered axles with a 77.5-inch length and axle centers of 60.75 inches. The triaxle location ranges from 92 to 188 inches on 4-inch centers, ensuring optimal load distribution and balance.

Advanced Features for Enhanced Performance of 40ft-45ft-48ft-53 Extendable Chassis

The 40ft-45ft-48ft-53ft Extendable Chassis is equipped with a range of advanced features designed to enhance performance and ease of use. The slider mechanism includes manual locking pins, ensuring secure adjustments and easy operation. The electrical system features a 12-volt, 7-way split pin receptacle plug and modular wiring, providing reliable and safe power distribution for lighting and other electrical components.

The braking system includes steel outboard-mounted drums, synthetic grease lubrication, and a 2S1M brake system type with 30/30 brake chambers. This system ensures reliable stopping power and safe operation, even under heavy loads.

Technical Specifications

• Overall Length: 40.6 feet (closed) to 53.6 feet (extended)
• Overall Width: 102 inches
• Fifth Wheel Height: 48 inches
• Tare Weight: Approximately 10,800 lbs
• GVWR: 90,000 lbs
• Axle Type: 5-inch round, tapered, 77.5 inches long
• Axle Quantity: Three, with 60.75-inch axle centers
• Suspension Type: Sliding one-leaf spring ride
• Landing Gear: AAR-approved, square leg with 55,000-lb lift capacity and 160,000-lb static load capacity

Benefits of the 40ft-45ft-48ft-53 Extendable Chassis

Versatility in Transport: The ability to carry 40-foot to 53-foot containers makes this chassis an adaptable solution for a variety of transport needs.

Strength and Durability: Built with high-quality materials, including Grade 50 steel, this chassis is engineered to withstand the demands of heavy-duty transport.

Compliance and Safety: Fully compliant with DOT, AAR, ANSI, TOFC, FMVSS, SAE, and TTMA standards, this chassis ensures safe and reliable operations.

Advanced Features: Equipped with manual locking pins, a modular wiring harness, and a robust braking system, this chassis is designed for enhanced performance and ease of use.
